PackTesting
End-of-line pack validation up to 500V and ±100A, with regenerative discharge that feeds energy back to the grid.
Contact UsPack Testing specifications
| Feature | Specification |
|---|---|
| Test Range | 0.2V–500V Wide Voltage Testing Range |
| Current Output | ±100A Bidirectional Charge & Discharge |
| Output Power | Up to 50kW Per Channel |
| Accuracy | ±0.05% Full Scale High Precision |
| Charging Modes | CC, CV, CCCV, Constant Power & Float Charging |
| Battery Communication | Built-in CAN 2.0A / 2.0B & RS485 BMS Communication |
| Data Analysis | Real-Time Graphs, Curves & Excel/TXT Export |
| Protection System | Comprehensive Hardware & Software Safety Protection |
| Energy Saving | ≥90% Energy Feedback Efficiency to the Grid |
| Smart Software | Programmable Test Sequences with Up to 10,000 Steps & Cycles |
Contact to get a Service
Our team of experts is ready to help you with all your battery testing requirements. Reach out to us today to schedule a consultation.
